TE5950 | TwinCAT 3 Drive Manager 2

The TwinCAT 3 Drive Manager 2 is used for commissioning the AX8000 multi-axis servo system, AX5000 digital compact servo drive, AMP8000 distributed servo drive system, AMI8100 integrated servo drives or the EL72xx, EL74xx, EL70x7, ELM72xx, EP72xx and EJ72xx I/O components. It is optionally available as an integrated version in the TwinCAT automation platform or an update version independently of TwinCAT. The TwinCAT 3 Drive Manager 2 is integrated into a TwinCAT solution as a project and enables a separate assessment of power supply modules, axis modules and axis channels.

Automatic start-up list

The menu structure enables intuitive axis commissioning. Via the electronic nameplate, TwinCAT 3 Drive Manager 2 automatically identifies the motor and corresponding parameter data. As a result, a start-up list is automatically generated for each axis.

Scope View is integrated

Using the Run Motor function, the motor is ready for operation with an NC control system. The combination of NC control with the Scope View tool provides an optimal overview of the motor in operation. A fine-tuning of the axis and a minimization of the tracking error is easy and straightforward.

Further adaptations are possible directly in the TwinCAT 3 Drive Manager 2 via the Tune Drive function, such as the adjustment of parameter settings and the configuration of filters.
