CX8210 | Embedded PC with EtherCAT
The CX8210 Embedded PC is a control with an EtherCAT slave interface. It features an Arm® Cortex®-A53 dual-core processor with 1.2 GHz. The basic configuration of the CX8200 includes a 1 Gbit Ethernet interface, a USB 3.0 interface, a 1 GB LPDDR4 RAM, and a slot for a microSD card. The microSD card is not included in the scope of delivery and must be ordered separately, taking the desired memory capacity into account.
E-bus or K-bus terminals can be attached as required; the CX8210 automatically recognizes the type of I/O system connected during the start-up phase. The control system is programmed with TwinCAT 3 via the Ethernet interface. TwinCAT 3 licenses must be ordered via the TwinCAT 3 price list.
Beckhoff RT Linux® is used as operating system.
Product status:
product announcement | estimated market release 1st quarter 2025
Product information
| Technical data | CX8210 |
|---|---|
| Processor | Arm® Cortex®-A53, 1.2 GHz |
| Number of cores | 2 |
| Flash memory | slot for microSD card, card not included (requires a microSD card with a minimum capacity of 16 GB) |
| Main memory | 1 GB LPDDR4 RAM (not expandable) |
| 1-second UPS | integrated (1 MB on microSD card) |
| Interfaces | 1 x RJ45 10/100/1000 Mbit/s, 1 x USB 3.0, 1 x bus interface |
| Cooling | passive |
| Bus interface | EtherCAT Slave IN and OUT (2 x RJ45) |
| Data transfer rates | 100 Mbit/s |
| Diagnostics LED | 1 x TC status, 1 x EC Run, 1 x EC Err |
| Clock | internal, capacitor-buffered real-time clock for time and date (storage capacity > 21 days) |
| Operating system | Beckhoff RT Linux® |
| Control software | TwinCAT 3 runtime (XAR) from TwinCAT 3.1 Build 4026 |
| I/O connection | E-bus or K-bus, automatic recognition |
| Power supply | 24 V DC (-15%/+20%) |
| Current supply E-bus/K-bus | 2 A |
| Max. power consumption | 4 W |
| Max. power consumption (with loading UPS) | 7.5 W |
| Max. power consumption E-bus/K-bus | 10 W (5 V/max. 2 A) |
| Dimensions (W x H x D) | 71 mm x 100 mm x 73 mm |
| Weight | approx. 220 g |
| Operating/storage temperature | -25…+60°C/-40…+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protection rating | IP20 |
| Approvals/markings | CE, UL |
| TwinCAT 3 platform level | Economy (20); please see here for an overview of all the TwinCAT 3 platform level |
| Accessories | |
|---|---|
| CX1900-0132 | 16 GB microSD card |
