针对大数据应用的多核示波软件
TwinCAT 3 Scope — 集成化的图表工具可以简单直观显示信号曲线
TwinCAT Scope 使得测量应用变得尽可能得简单，即便是对于“大数据”的应用：对多核处理的支持也使得采集和显示更庞大的数据量成为可能。示波软件全集成在 TwinCAT 系统架构内，能够通过使用绘图工具简化信号曲线的图形显示。
产品
TE1000 | TwinCAT 3 开发环境
TE1000 用于方便地在 TwinCAT 开发环境中配置控制器、驱动器和 I/O。此外，使用该工具还能够配置和编程倍福的 TwinSAFE 安全解决方案。
TE1300 | TwinCAT 3 Scope View Professional
The TwinCAT 3 Scope View is a software oscilloscope for the graphic representation of signal curves in different chart types. These could be, for example, YT, XY, bar or digital charts. The Scope View Professional extends the Scope View Base version supplied with TwinCAT 3 XAE by additional functionalities. The field of application refers to processes that are to be tracked and monitored over a longer period of time.
TF3300 | TwinCAT 3 Scope Server
The TwinCAT 3 Scope Server prepares data for the graphical display in the TwinCAT 3 Scope View. It can be used with the Scope View Base or the TE1300 Scope View Professional version. The Scope Server is particularly suitable for autonomous data recording in distributed systems in the production, plant or machine network. It not only has TwinCAT-specific communication interfaces, but also a standardized communication connection via OPC UA.
